Samvolt High Voltage Battery

Samvolt's high-voltage battery is an advanced energy storage solution with LFP technology that combines safety, flexibility, and high performance for homes and businesses.

Benefits

Flexible capacity - Modular design from 5 kWh up to 60 kWh. Ability to combine new and old modules for easy upgrade.

High Voltage Technology - Operates at around 400V with built-in DC/DC optimizers for superior efficiency and minimal power loss.

Safety and durability - LFP batteries with IP65 rating for indoor and outdoor installation. 10 year warranty.

Back-up and black start - Ensures power supply even in the event of a power outage.

Easy integration - Compatible with Solinteg and other inverters. Communication via CAN2.0, RS485, WiFi and LAN.

Technical Specifications

Models: 5 kWh / 10 kWh / 15 kWh / 20 kWh

Usable capacity: 4.5 / 9 / 13.5 / 18 kWh (90% DoD)

Battery type: LFP (Lithium Iron Phosphate)

Voltage: 400V (350-450V)

Charging/discharging: 2.5 / 5 / 7.5 / 10 kW

Scalability: Maximum 3 in parallel (60 kWh)

Dimensions (W/D/H): 653 × (597/912/1227/1542) × 189 mm

Weight: 67 / 119 / 171 / 223 kg

Operating temperature: -10°C to +50°C

Protection class: IP65

Warranty: 10 years

Certifications: IEC62619, CE, UN38.3
