Solis 12kW Inverter & Enershare 9.6kWh Battery System

This package offers a powerful and intelligent solution for energy storage in medium-sized photovoltaic systems. It combines the efficient Solis S6-EH3P12K-H three-phase hybrid inverter with a reliable Enershare Energy-Core battery system of 9.6kWh, providing a flexible and future-proof system for both residential and business needs.

Package benefits: The Solis inverter provides high efficiency, automatic UPS switching with backup breaker time below 10 ms, and several smart features such as four individual MPPTs for optimized production from solar panels on different roof surfaces. Built with safe LFP technology, the Enershare battery allows for easy expansion and installation thanks to modular plug-and-play design as well as auto-configuring BMS.

Technical Specifications – Solis S6-EH3P12K-H Inverter

Model: S6-EH3P12K-H
Rated output power: 12 kW
Maximum rated output power: 12 kVA
Max charge/discharge current: 50 A
Battery voltage range: 120-800 V
Maximum efficiency: 97.6%
EU efficiency: 97.5%
MPPT voltage range: 200-850 V
MPPT Number: 4
Protection class: IP66
Back-up switch time: <10 ms
Dimensions (WxHxD): 599 x 546 x 243 mm
Weight: 31.7 kg
Warranty: 5 years

Technical Specifications – Enershare Energy-Core Battery System (9.6kWh)

Total usable energy: 9.6 kWh (3 modules of 3.2 kWh)
Number of modules: 3
Nominal voltage: 192 V
Operating voltage range: 162~219 V
Maximum Output Current: 30 A
Peak Output Current: 50 A (5s)
Protection class: IP65
Dimensions (H, WD): 975 x 650 x 260 mm
Weight: 129.5 kg
Warranty: 10 years
Battery Cell Technology: LFP
Scalability: Up to 6 towers in parallel

Installation wizard

Enershare CORE - Snabbguide för Installatörer

Enershare Product Sheet

Enershare English User Manual

Enershare Quick Start

Enershare Compatibility

Solis Product sheet 12kW

Solis Manual 12kW

Solis+Enershare package 12kW / 9.6kWh
