Battery pack Villa with 18.9 kWh Battery capacity incl. BMS Hanchu's battery pack for villa with 7 pieces of 2.7 kWh high voltage battery modules is a state-of-the-art energy storage solution, designed to offer high flexibility, safety, and intelligent control for home and small business applications.

Leading Technology

Compact and modular design: Allows for greater flexibility in installation and operation.
Higher DOD (Depth of Discharge): 95% for more usable energy.
Extreme lightness and thinness: Facilitates quick installation by one person.

Intelligent Platform

Predictive and problem-solving service: Online services for fast and timely problem solving.
Smart power management: 24/7 real-time monitoring and remote diagnostics or upgrades.

Ultra Security

Built-in Aerosol System for Fire Protection: Improved fire safety.
Improved heat dissipation structure: For longer service life and safe operation.
High-quality lithium iron phosphate (LiFePO4): For long life cycle.

Technical Specification

Module Energy: 2.7 kWh
Module Weight: 25.4 kg
Operating voltage: 144-460.8V depending on the number of modules
Maximum charge/discharge current: 50A
Depth of discharge (DOD): 95%
Cyclic life: >6000 cycles at 25°C
Protection class: IP65
Charging temperature: -5 to 55°C
Discharge temperature: -20 to 55°C
Communication: CAN/RS485/WIFI/Bluetooth
Safety and transport certification: IEC 62619/IEC 62477/CE, UN38.3

Design and Installation

Modular system: Supports up to 12 devices in series.
Natural convection: For cooling without the need for external fans.
Protection from ambient conditions: Operates in humidity levels between 5% and 95%, and at altitudes below 2000 meters.

Warranty and Support

Warranty: 10 years
Support: 24/7 cloud-based monitoring and remote support via an intelligent platform.
